Product image shown for identification purposes only.
22 (22P+0E) Cores 44 Threads @ 4.80 GHz | FCLGA4677
The Intel Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz) is a workstation processor for the FCLGA4677 platform, based on the Sapphire Rapids architecture (Intel 7). It features 22 (22P+0E) cores and 44 threads, with a base frequency of 3 GHz and boost up to 4.80 GHz. The CPU has 45 MB of cache with a 250 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Sapphire Rapids |
| Series | Xeon W-2500 |
| Launch Date | Q3'24 |
| Cores / Threads | 22 (22P+0E) / 44 |
| Process | Intel 7 |
| Socket | FCLGA4677 |
| Unlocked | Yes |
| Spec Code | SRN4D |
| Stepping | S3 |
| Intel SKU | 236879 |
| Base Clock | 3 GHz |
| Max Turbo Clock | 4.80 GHz |
| L3 Cache | 45 MB |
| Memory Type | DDR5 |
| Memory Speed | 4800 MT/s |
| Memory Channels | 4 |
| Max Memory | 2048 GB |
| Base Power (TDP) | 250 W |
| Max Turbo Power | 300 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 64 |
| Ordering Code | BX807132575X |
| Package | Box |
The Intel Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz) uses the FCLGA4677 socket (Xeon W-2500 platform).
The Intel Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz) supports DDR5 with a maximum of 2048 GB.
The Intel Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz) has 22 (22P+0E) cores and 44 threads, with a max turbo frequency of 4.80 GHz.
The Intel Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz) has a base power (TDP) of 250 W and max turbo power of 300 W.
