Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz)
INTEL PRODUCT

Product image shown for identification purposes only.

Contact for Price
Comparing processors? Open Comparison Tool →
INTEL

Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) (BX807132565X)

18 (18P+0E) Cores 36 Threads @ 4.80 GHz | FCLGA4677

Total CPU cores: 18 (18P+0E). P-cores handle heavy workloads, E-cores handle background tasks.
Cores18 (18P+0E)
Maximum single-core turbo frequency under Intel Turbo Boost Technology.
Max Boost4.80 GHz
Total cache (L2 + L3) for fast data access during compute-intensive tasks.
Cache37.5 MB
Base power consumption (TDP). Ensure adequate cooling and PSU capacity.
TDP240W
BoxBX807132565X
TrayPK8071305502000
CategoryWorkstation Processors
Technical Snapshot

The Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) is a workstation processor for the FCLGA4677 platform, based on the Sapphire Rapids architecture (Intel 7). It features 18 (18P+0E) cores and 36 threads, with a base frequency of 3.20 GHz and boost up to 4.80 GHz. The CPU has 37.5 MB of cache with a 240 W base TDP. Memory support includes DDR5.

Use Case
Professional workstations
Compatibility
FCLGA4677 motherboard (Xeon W-2500)
Category
Workstation Processor — Sapphire Rapids

Key Specifications

SocketFCLGA4677
P-Cores18
Base Clock3.20 GHz
Boost Clock4.80 GHz
L3 Cache37.5 MB
Base TDP240W
Turbo Power288W
MemoryDDR5

Full Specifications

Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)

Processor Architecture
CodenameSapphire Rapids
SeriesXeon W-2500
Launch DateQ3'24
Cores / Threads18 (18P+0E) / 36
ProcessIntel 7
SocketFCLGA4677
UnlockedYes
Spec CodeSRN4E
SteppingS3
Intel SKU236883
Performance
Base Clock3.20 GHz
Max Turbo Clock4.80 GHz
Cache
L3 Cache37.5 MB
Memory
Memory TypeDDR5
Memory Speed4800 MT/s
Memory Channels4
Max Memory2048 GB
Power
Base Power (TDP)240 W
Max Turbo Power288 W
Connectivity
PCIe Version5.0
PCIe Lanes64
Product Information
Ordering Code (Box)BX807132565X
Ordering Code (Tray)PK8071305502000
PackageBox, Tray

Support & Downloads

Latest Drivers & SoftwareVisit Intel for the latest updates
Intel Downloads →
Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) SpecificationsProduct specifications on Intel ARK
View on Intel →

Related Processors

Intel® Xeon® w3-2525 (22.5M Cache, 3.50 GHz)
8 Cores · 4.50 GHz
View Product →
Intel® Xeon® w3-2535 (26.25M Cache, 3.50 GHz)
10 Cores · 4.60 GHz
View Product →
Intel® Xeon® w5-2545 (30M Cache, 3.50 GHz)
12 Cores · 4.70 GHz
View Product →
Intel® Xeon® w5-2555X (33.75M Cache, 3.30 GHz)
14 Cores · 4.80 GHz
View Product →
Intel® Xeon® w7-2575X (45M Cache, 3.00 GHz)
22 Cores · 4.80 GHz
View Product →
← Back to Intel Workstation CPU Catalog

Frequently Asked Questions

What socket does the Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) use?

The Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) uses the FCLGA4677 socket (Xeon W-2500 platform).

What memory does the Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) support?

The Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) supports DDR5 with a maximum of 2048 GB.

How many cores does the Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) have?

The Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) has 18 (18P+0E) cores and 36 threads, with a max turbo frequency of 4.80 GHz.

What is the TDP of the Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz)?

The Intel Intel® Xeon® w5-2565X (37.5M Cache, 3.20 GHz) has a base power (TDP) of 240 W and max turbo power of 288 W.
