24 Cores 48 Threads @ 3.70 GHz | FCLGA4677
The Intel Intel® Xeon® Silver 4516Y+ (45M Cache, 2.20 GHz) is a server processor for the FCLGA4677 platform, based on the Emerald Rapids architecture (Intel 7). It features 24 cores and 48 threads, with a base frequency of 2.20 GHz and boost up to 3.70 GHz. The CPU has 45 MB of cache with a 185 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Emerald Rapids |
| Series | Xeon Scalable 5th Gen |
| Launch Date | Q4'23 |
| Cores / Threads | 24 / 48 |
| Process | Intel 7 |
| Socket | FCLGA4677 |
| Spec Code | SRN6K |
| Stepping | R1 |
| Intel SKU | 237556 |
| Base Clock | 2.20 GHz |
| Max Turbo Clock | 3.70 GHz |
| L3 Cache | 45 MB |
| Memory Type | DDR5 |
| Memory Speed | 4400 MT/s |
| Memory Channels | 8 |
| Max Memory | 4096 GB |
| Base Power (TDP) | 185 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 80 |
| Ordering Code (Box) | BX807224516Y |
| Ordering Code (Tray) | PK8072205559200 |
| Package | Box, Tray |
The Intel Intel® Xeon® Silver 4516Y+ (45M Cache, 2.20 GHz) uses the FCLGA4677 socket (Xeon Scalable 5th Gen platform).
The Intel Intel® Xeon® Silver 4516Y+ (45M Cache, 2.20 GHz) supports DDR5 with a maximum of 4096 GB.
The Intel Intel® Xeon® Silver 4516Y+ (45M Cache, 2.20 GHz) has 24 cores and 48 threads, with a max turbo frequency of 3.70 GHz.
The Intel Intel® Xeon® Silver 4516Y+ (45M Cache, 2.20 GHz) has a base power (TDP) of 185 W.
