8 Cores 16 Threads @ 4.10 GHz | FCLGA4677
Note: this chart shows historical reference pricing for trend insight only — it is not a live quote. To place an order or get current pricing, please contact us or your dedicated sales manager.
The Intel Intel® Xeon® Silver 4509Y (22.5M Cache, 2.60 GHz) is a server processor for the FCLGA4677 platform, based on the Sapphire Rapids architecture (Intel 7). It features 8 cores and 16 threads, with a base frequency of 2.60 GHz and boost up to 4.10 GHz. The CPU has 22.5 MB of cache with a 125 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Sapphire Rapids |
| Series | Xeon Scalable 5th Gen |
| Launch Date | Q4'23 |
| Cores / Threads | 8 / 16 |
| Process | Intel 7 |
| Socket | FCLGA4677 |
| Spec Code | SRN61 |
| Stepping | U1 |
| Intel SKU | 236636 |
| Base Clock | 2.60 GHz |
| Max Turbo Clock | 4.10 GHz |
| L3 Cache | 22.5 MB |
| Memory Type | DDR5 |
| Memory Speed | 4400 MT/s |
| Memory Channels | 8 |
| Max Memory | 4096 GB |
| Base Power (TDP) | 125 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 80 |
| Ordering Code | PK8071305554400 |
| Package | Tray |
The Intel Intel® Xeon® Silver 4509Y (22.5M Cache, 2.60 GHz) uses the FCLGA4677 socket (Xeon Scalable 5th Gen platform).
The Intel Intel® Xeon® Silver 4509Y (22.5M Cache, 2.60 GHz) supports DDR5 with a maximum of 4096 GB.
The Intel Intel® Xeon® Silver 4509Y (22.5M Cache, 2.60 GHz) has 8 cores and 16 threads, with a max turbo frequency of 4.10 GHz.
The Intel Intel® Xeon® Silver 4509Y (22.5M Cache, 2.60 GHz) has a base power (TDP) of 125 W.
