6 Cores 12 Threads @ 5 GHz | FCLGA1700
The Intel Intel® Xeon® E-2436 (18M Cache, 2.90 GHz) is a server processor for the FCLGA1700 platform, based on the Raptor Lake architecture (Intel 7). It features 6 cores and 12 threads, with a base frequency of 2.90 GHz and boost up to 5 GHz. The CPU has 18 MB of cache with a 65 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Raptor Lake |
| Series | Xeon E-2400 |
| Launch Date | Q4'23 |
| Cores / Threads | 6 / 12 |
| Process | Intel 7 |
| Socket | FCLGA1700 |
| Spec Code | SRMXB |
| Stepping | B0 |
| Intel SKU | 236190 |
| Base Clock | 2.90 GHz |
| Max Turbo Clock | 5 GHz |
| L3 Cache | 18 MB |
| Memory Type | DDR5 |
| Memory Speed | 4800 MT/s |
| Memory Channels | 2 |
| Max Memory | 128 GB |
| Base Power (TDP) | 65 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 20 |
| Ordering Code (Box) | BX80715E2436 |
| Ordering Code (Tray) | CM8071505025005 |
| Package | Box, Tray |
The Intel Intel® Xeon® E-2436 (18M Cache, 2.90 GHz) uses the FCLGA1700 socket (Xeon E-2400 platform).
The Intel Intel® Xeon® E-2436 (18M Cache, 2.90 GHz) supports DDR5 with a maximum of 128 GB.
The Intel Intel® Xeon® E-2436 (18M Cache, 2.90 GHz) has 6 cores and 12 threads, with a max turbo frequency of 5 GHz.
The Intel Intel® Xeon® E-2436 (18M Cache, 2.90 GHz) has a base power (TDP) of 65 W.
