BR No. 56560761
4 Cores 8 Threads @ 5.00GHz | FCLGA1700
| Tray | CM8071505025205 S-Spec SRMXC |
| Box | BX80715E2434 S-Spec SRMXC |
Quote by tray or boxed part number. All tray CPU part numbers
Reference price US$540 · request a quote for volume pricing
Note: this chart shows historical reference pricing for trend insight only — it is not a live quote. To place an order or get current pricing, please contact us or your dedicated sales manager.
The Intel Xeon E-2434 is a server processor for the FCLGA1700 platform, based on the Products formerly Raptor Lake architecture (Intel 7). It features 4 cores and 8 threads, with a base frequency of 3.40GHz and boost up to 5.00GHz. The CPU has 12 MB MB of cache with a 55 W W base TDP. Memory support includes DDR5-4800.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Products formerly Raptor Lake |
| Series | Xeon E-2400 |
| Launch Date | Q4'23 |
| Cores / Threads | 4 / 8 |
| Process | Intel 7 |
| Socket | FCLGA1700 |
| Spec Code | SRMXC |
| Stepping | B0 |
| Intel SKU | 236192 |
| Base Clock | 3.40GHz |
| Max Turbo Clock | 5.00GHz |
| L3 Cache | 12 MB MB |
| Memory Type | DDR5-4800 |
| Memory Speed | 4800 MT/s |
| Memory Channels | 2 |
| Max Memory | 128 GB GB |
| ECC Memory | Yes |
| Scalability | 1S |
| Base Power (TDP) | 55 W W |
| PCIe Version | 5 |
| PCIe Lanes | 20 |
| Ordering Code (Box) | BX80715E2434 |
| Ordering Code (Tray) | CM8071505025205 |
| Package | Box, Tray |
The Intel Xeon E-2434 is the same processor in two packagings — the tray (OEM) version and the boxed (retail) version. Quote by either part number.
| Tray (OEM) | Boxed (Retail) | |
| Part number | CM8071505025205 (SRMXC) | BX80715E2434 (SRMXC) |
| Packaging | Bulk tray | Retail box |
| Cooler | Not included | As shipped by Intel |
| Warranty | Seller / OEM terms | Intel retail warranty |
Both are the same chip with the same processor number — all tray CPU part numbers.
The Intel Xeon E-2434 uses the FCLGA1700 socket (Xeon E-2400 platform).
The Intel Xeon E-2434 supports DDR5-4800 with a maximum of 128 GB GB.
The Intel Xeon E-2434 has 4 cores and 8 threads, with a max turbo frequency of 5.00GHz.
The Intel Xeon E-2434 has a base power (TDP) of 55 W W.
