52 Cores 104 Threads @ 3.50 GHz | FCLGA4677
The Intel Intel® Xeon® CPU Max 9470 (105M Cache, 2.00 GHz) is a server processor for the FCLGA4677 platform, based on the Sapphire Rapids HBM architecture (Intel 7). It features 52 cores and 104 threads, with a base frequency of 2 GHz and boost up to 3.50 GHz. The CPU has 105 MB of cache with a 350 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Sapphire Rapids HBM |
| Series | Xeon Max |
| Launch Date | Q1'23 |
| Cores / Threads | 52 / 104 |
| Process | Intel 7 |
| Socket | FCLGA4677 |
| Spec Code | SRMJC |
| Stepping | B3 |
| Intel SKU | 232594 |
| Base Clock | 2 GHz |
| Max Turbo Clock | 3.50 GHz |
| L3 Cache | 105 MB |
| Memory Type | DDR5 |
| Memory Speed | 4800 MT/s |
| Memory Channels | 8 |
| Max Memory | 4096 GB |
| Base Power (TDP) | 350 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 80 |
| Ordering Code | PK8071305223200 |
| Package | Tray |
The Intel Intel® Xeon® CPU Max 9470 (105M Cache, 2.00 GHz) uses the FCLGA4677 socket (Xeon Max platform).
The Intel Intel® Xeon® CPU Max 9470 (105M Cache, 2.00 GHz) supports DDR5 with a maximum of 4096 GB.
The Intel Intel® Xeon® CPU Max 9470 (105M Cache, 2.00 GHz) has 52 cores and 104 threads, with a max turbo frequency of 3.50 GHz.
The Intel Intel® Xeon® CPU Max 9470 (105M Cache, 2.00 GHz) has a base power (TDP) of 350 W.
