Product image shown for identification purposes only.
6 Cores 12 Threads @ 5 GHz | FCLGA1200
The Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) is a server processor for the FCLGA1200 platform, based on the Rocket Lake architecture (14 nm). It features 6 cores and 12 threads, with a base frequency of 3.20 GHz and boost up to 5 GHz. The CPU has 12 MB of cache with a 80 W base TDP. Memory support includes DDR4.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Rocket Lake |
| Series | Xeon E-2300 |
| Launch Date | Q3'21 |
| Cores / Threads | 6 / 12 |
| Process | 14 nm |
| Socket | FCLGA1200 |
| Spec Code | SRKN2 |
| Stepping | B0 |
| Intel SKU | 212257 |
| Base Clock | 3.20 GHz |
| Max Turbo Clock | 5 GHz |
| L3 Cache | 12 MB |
| Memory Type | DDR4 |
| Memory Speed | 3200 MT/s |
| Memory Channels | 2 |
| Max Memory | 128 GB |
| Base Power (TDP) | 80 W |
| Integrated Graphics | Intel UHD Graphics P750 |
| PCIe Version | 4.0 |
| PCIe Lanes | 20 |
| Ordering Code | CM8070804495016 |
| Package | Tray |
The Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) uses the FCLGA1200 socket (Xeon E-2300 platform).
The Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) supports DDR4 with a maximum of 128 GB.
The Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) has 6 cores and 12 threads, with a max turbo frequency of 5 GHz.
The Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) has a base power (TDP) of 80 W.
Yes, the Intel Intel® Xeon® E-2356G (12M Cache, 3.20 GHz) includes Intel UHD Graphics P750.
