INTEL
Intel Xeon 6767P Tray PK8072006269900 (SRV5F)
64 Cores 128 Threads @ 3.9 GHz | FCLGA4710
MPNPK8072006269900
PackageTray
CategoryServer Processors
Ordering codes
| Tray | PK8072006269900 S-Spec SRV5F |
Quote by tray or boxed part number. All tray CPU part numbers
Full Specifications
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
Processor Architecture
| Codename | Granite Rapids |
| Series | Xeon 6700P |
| Launch Date | Q1'25 |
| Cores / Threads | 64 / 128 |
| Process | Intel 3 |
| Socket | FCLGA4710 |
| Spec Code | SRV5F |
| Stepping | B2 |
| Intel SKU | 241845 |
Performance
| Base Clock | 2.4 GHz |
| Max Turbo Clock | 3.9 GHz |
Cache
| L3 Cache | 336 MB |
Memory
| Memory Type | DDR5 |
| Memory Speed | 8000 MT/s |
| Memory Channels | 8 |
| Max Memory | 4096 GB |
| ECC Memory | Yes |
Platform
| Scalability | 2S |
Power
| Base Power (TDP) | 350 W |
Connectivity
| PCIe Version | 5.0 |
| PCIe Lanes | 88 |
Product Information
| Ordering Code | PK8072006269900 |
| Package | Tray |
