Product image shown for identification purposes only.
48 Cores 96 Threads @ 3.80 GHz | FCLGA4710
The Intel Intel® Xeon® 6740P (288M Cache, 2.10 GHz) is a server processor for the FCLGA4710 platform, based on the Granite Rapids architecture (Intel 3). It features 48 cores and 96 threads, with a base frequency of 2.10 GHz and boost up to 3.80 GHz. The CPU has 288 MB of cache with a 270 W base TDP. Memory support includes DDR5.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Granite Rapids |
| Series | Xeon 6700P |
| Launch Date | Q1'25 |
| Cores / Threads | 48 / 96 |
| Process | Intel 3 |
| Socket | FCLGA4710 |
| Spec Code | SRV5H |
| Stepping | B2 |
| Intel SKU | 241838 |
| Base Clock | 2.10 GHz |
| Max Turbo Clock | 3.80 GHz |
| L3 Cache | 288 MB |
| Memory Type | DDR5 |
| Memory Speed | 6400 MT/s |
| Memory Channels | 8 |
| Max Memory | 4096 GB |
| Base Power (TDP) | 270 W |
| PCIe Version | 5.0 |
| PCIe Lanes | 88 |
| Ordering Code | PK8072006270100 |
| Package | Tray |
The Intel Intel® Xeon® 6740P (288M Cache, 2.10 GHz) uses the FCLGA4710 socket (Xeon 6700P platform).
The Intel Intel® Xeon® 6740P (288M Cache, 2.10 GHz) supports DDR5 with a maximum of 4096 GB.
The Intel Intel® Xeon® 6740P (288M Cache, 2.10 GHz) has 48 cores and 96 threads, with a max turbo frequency of 3.80 GHz.
The Intel Intel® Xeon® 6740P (288M Cache, 2.10 GHz) has a base power (TDP) of 270 W.
