The Intel Core Ultra 5 245KF is a desktop processor for the FCLGA1851 platform, based on the Arrow Lake architecture (Intel 20A). It features 14 (6P+8E) cores and 14 threads, with a base frequency of 4.2 GHz and boost up to 5.2 GHz. The CPU has 24.0 MB of cache with a 125 W base TDP. Memory support includes DDR5 6400 MT/s.
14 (6P+8E) Cores 14 Threads @ 5.2 GHz | FCLGA1851
| Codename | Arrow Lake |
| Series | Core Ultra 200S |
| Cores / Threads | 14 (6P+8E) / 14 |
| Process | Intel 20A |
| Socket | FCLGA1851 |
| Base Clock | 4.2 GHz |
| Max Turbo Clock | 5.2 GHz |
| Total Cache | 24.0 MB |
| L2 Cache | 26.0 MB |
| Memory Type | DDR5 6400 MT/s |
| Max Memory | 256 GB |
| Base Power (TDP) | 125 W |
| Max Turbo Power | 159 W |
| Integrated Graphics | Discrete GPU Required |
| PCIe Version | 5.0 and 4.0 |
| PCIe Lanes | 24 |
| Ordering Code | BXC80768245KF |
| Package | Box |
The Intel Core Ultra 5 245KF uses the FCLGA1851 socket, compatible with Core Ultra 200S-generation Intel motherboards.
The Intel Core Ultra 5 245KF supports DDR5 6400 MT/s with a maximum of 256 GB.
The Intel Core Ultra 5 245KF has 14 (6P+8E) cores and 14 threads, with a max turbo frequency of 5.2 GHz.
The Intel Core Ultra 5 245KF has a base power (TDP) of 125 W and max turbo power of 159 W.
No, the Intel Core Ultra 5 245KF requires a discrete graphics card.
