BR No. 56560761
24 (8P+16E) Cores 32 Threads @ 5.8GHz | FCLGA1700
| Tray | CM8071504820609 S-Spec SRN3V |
| Box | BX8071514900 S-Spec SRN3V |
| Box | BXC8071514900 S-Spec SRN3V |
Quote by tray or boxed part number. All tray CPU part numbers
Reference price US$448 · request a quote for volume pricing
Note: this chart shows historical reference pricing for trend insight only — it is not a live quote. To place an order or get current pricing, please contact us or your dedicated sales manager.
The Intel Core i9-14900 is a desktop processor for the FCLGA1700 platform, based on the Raptor Lake architecture (Intel 7). It features 24 (8P+16E) cores and 32 threads, with a base frequency of 2GHz and boost up to 5.8GHz. The CPU has 36 MB of cache with a 65 W base TDP. Memory support includes DDR5, DDR4.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Raptor Lake |
| Series | Core i9 14th Gen |
| Launch Date | Q1'24 |
| Cores / Threads | 24 (8P+16E) / 32 |
| Process | Intel 7 |
| Socket | FCLGA1700 |
| Unlocked | No |
| Spec Code | SRN3V |
| Stepping | B0 |
| Intel SKU | 236793 |
| Base Clock | 2GHz |
| Max Turbo Clock | 5.8GHz |
| L3 Cache | 36 MB |
| L2 Cache | 32 MB |
| Memory Type | DDR5, DDR4 |
| Memory Speed | DDR5 5600 MT/s, DDR4 3200 MT/s |
| Memory Channels | 2 |
| Max Memory | 192 GB |
| Base Power (TDP) | 65 W |
| Max Turbo Power | 219 W |
| Integrated Graphics | Intel UHD Graphics 770 |
| PCIe Version | 5.0, 4.0 |
| PCIe Lanes | 20 |
| Ordering Code (Box) | BX8071514900 |
| Ordering Code (Box) | BXC8071514900 |
| Ordering Code (Tray) | CM8071504820609 |
| Package | Box, Tray |
The Intel Core i9-14900 is the same processor in two packagings — the tray (OEM) version and the boxed (retail) version. Quote by either part number.
| Tray (OEM) | Boxed (Retail) | |
| Part number | CM8071504820609 (SRN3V) | BX8071514900 (SRN3V), BXC8071514900 (SRN3V) |
| Packaging | Bulk tray | Retail box |
| Cooler | Not included | As shipped by Intel |
| Warranty | Seller / OEM terms | Intel retail warranty |
Both are the same chip with the same processor number — all tray CPU part numbers.
Evergreen Computer Technology Company supplies this processor wholesale from Hong Kong to system integrators, resellers and enterprise buyers. Quote by tray or boxed part number — lead time and pricing are confirmed on your quotation.
The Intel Core i9-14900 uses the FCLGA1700 socket (Core i9 14th Gen platform).
The Intel Core i9-14900 supports DDR5, DDR4 with a maximum of 192 GB.
The Intel Core i9-14900 has 24 (8P+16E) cores and 32 threads, with a max turbo frequency of 5.8GHz.
The Intel Core i9-14900 has a base power (TDP) of 65 W and max turbo power of 219 W.
Yes, the Intel Core i9-14900 includes Intel UHD Graphics 770.
