Technical Snapshot

The Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 is a desktop processor for the FCLGA1700 platform, based on the Raptor Lake architecture (Intel 7). It features 24 (8P+16E) cores and 32 threads, with a base frequency of 2.0 GHz and boost up to 5.6 GHz. The CPU has 36.0 MB of cache with a 65 W base TDP. Memory support includes DDR5 5600 MT/s / DDR4 3200 MT/s.

Use Case
Desktop computing, gaming, content creation
Compatibility
FCLGA1700 motherboard (13th Gen)
Category
Desktop Processor — Raptor Lake
Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700
INTEL PRODUCT
INTEL

Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700

24 (8P+16E) Cores 32 Threads @ 5.6 GHz | FCLGA1700

Total CPU cores: 24 (8P+16E). P-cores handle heavy workloads, E-cores handle background tasks.
Cores24 (8P+16E)
Maximum single-core turbo frequency under Intel Turbo Boost Technology.
Max Boost5.6 GHz
Total cache (L2 + L3) for fast data access during compute-intensive tasks.
Cache36.0 MB
Base power consumption (TDP). Ensure adequate cooling and PSU capacity.
TDP65W
BoxBX8071513900
BoxBXC8071513900
TrayCM8071504820605
CategoryDesktop Processors
Contact for Price
Comparing processors? Open Comparison Tool →

Key Specifications

SocketFCLGA1700
P-Cores8
E-Cores16
Base Clock2.0 GHz
Boost Clock5.6 GHz
L3 Cache36.0 MB
L2 Cache32.0 MB
Base TDP65W
Turbo Power219W
MemoryDDR5 5600 MT/s / DDR4 3200 MT/s

Full Specifications

Processor Architecture
CodenameRaptor Lake
Series13th Gen
Cores / Threads24 (8P+16E) / 32
ProcessIntel 7
SocketFCLGA1700
Performance
Base Clock2.0 GHz
Max Turbo Clock5.6 GHz
Cache
Total Cache36.0 MB
L2 Cache32.0 MB
Memory
Memory TypeDDR5 5600 MT/s / DDR4 3200 MT/s
Max Memory192 GB
Power
Base Power (TDP)65 W
Max Turbo Power219 W
Graphics
Integrated GraphicsIntel® UHD Graphics 770
Connectivity
PCIe Version5.0 and 4.0
PCIe Lanes20
Product Information
Ordering Code (Box)BX8071513900
Ordering Code (Box)BXC8071513900
Ordering Code (Tray)CM8071504820605
PackageBox, Tray

Support & Downloads

Latest Drivers & SoftwareVisit Intel for the latest updates
Intel Downloads →
Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 SpecificationsProduct specifications on Intel ARK
View on Intel →

Related Processors

Core i9-13900F Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700
24 Cores · 5.6 GHz
View Product →
Core i9-13900K Boxed 24C/32T 5.8GHz 36MB L3 125W LGA1700
24 Cores · 5.8 GHz
View Product →
Core i9-13900KF Boxed 24C/32T 5.8GHz 36MB L3 125W LGA1700
24 Cores · 5.8 GHz
View Product →
Core i9-13900KS Boxed 24C/32T 6.0GHz 36MB L3 150W LGA1700
24 Cores · 6.0 GHz
View Product →
Core i9-13900F Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700
24 Cores · 5.6 GHz
View Product →
← Back to Intel CPU Catalog

Frequently Asked Questions

What socket does the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 use?

The Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 uses the FCLGA1700 socket, compatible with 13th Gen-generation Intel motherboards.

What memory does the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 support?

The Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 supports DDR5 5600 MT/s / DDR4 3200 MT/s with a maximum of 192 GB.

How many cores does the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 have?

The Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 has 24 (8P+16E) cores and 32 threads, with a max turbo frequency of 5.6 GHz.

What is the TDP of the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700?

The Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 has a base power (TDP) of 65 W and max turbo power of 219 W.

Does the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 have integrated graphics?

Yes, the Intel Core i9-13900 Boxed 24C/32T 5.6GHz 36MB L3 65W LGA1700 includes Intel® UHD Graphics 770.
