BR No. 56560761
16 (8P+8E) Cores 24 Threads @ 5.1GHz | FCLGA1700
The Intel Core i9-12900 is a desktop processor for the FCLGA1700 platform, based on the Alder Lake architecture (Intel 7). It features 16 (8P+8E) cores and 24 threads, with a base frequency of 2.4GHz and boost up to 5.1GHz. The CPU has 30 MB of cache with a 65 W base TDP. Memory support includes DDR5, DDR4.
Manufacturer-verified specifications (Manufacturer-Verified (MV-1) · Source: Intel ARK)
| Codename | Alder Lake |
| Series | Core i9 12th Gen |
| Launch Date | Q1'22 |
| Cores / Threads | 16 (8P+8E) / 24 |
| Process | Intel 7 |
| Socket | FCLGA1700 |
| Unlocked | No |
| Spec Code | SRL4K |
| Stepping | C0 |
| Intel SKU | 134597 |
| Base Clock | 2.4GHz |
| Max Turbo Clock | 5.1GHz |
| L3 Cache | 30 MB |
| L2 Cache | 14 MB |
| Memory Type | DDR5, DDR4 |
| Memory Speed | DDR5 4800 MT/s, DDR4 3200 MT/s |
| Memory Channels | 2 |
| Max Memory | 128 GB |
| Base Power (TDP) | 65 W |
| Max Turbo Power | 202 W |
| Integrated Graphics | Intel UHD Graphics 770 |
| PCIe Version | 5.0, 4.0 |
| PCIe Lanes | 20 |
| Ordering Code (Box) | BX8071512900 |
| Ordering Code (Box) | BXC8071512900 |
| Package | Box |
Evergreen Computer Technology Company supplies this processor wholesale from Hong Kong to system integrators, resellers and enterprise buyers. Quote by tray or boxed part number — lead time and pricing are confirmed on your quotation.
The Intel Core i9-12900 uses the FCLGA1700 socket (Core i9 12th Gen platform).
The Intel Core i9-12900 supports DDR5, DDR4 with a maximum of 128 GB.
The Intel Core i9-12900 has 16 (8P+8E) cores and 24 threads, with a max turbo frequency of 5.1GHz.
The Intel Core i9-12900 has a base power (TDP) of 65 W and max turbo power of 202 W.
Yes, the Intel Core i9-12900 includes Intel UHD Graphics 770.
