INTEL
Core i7-11700F
11th Gen Intel Core i7-11700F desktop processor with 8 cores, 16 threads, up to 4.9 GHz Max Turbo Frequency, 16 MB Intel Smart Cache, 65W base TDP (224W Max Turbo Power), DDR4-3200 memory support, and PCIe 4.0. No integrated graphics (F-series) — a discrete GPU is required.
Ordering CodeBX8070811700F
PackageBox (Retail)
CategoryDesktop Processors
8
Cores
4.9 GHz
Max Turbo
16 MB
L3 Cache
16
Threads
65 W
Base Power
14nm
Process
Specifications sourced from Intel ARK. Last synced: March 9, 2026.
Full Specifications
Complete data sourced from Intel ARK — mapped to Evergreen canonical schema
Processor Architecture & Cores
| Codename | Rocket Lake (11th Gen) |
| Product Code | i7-11700F |
| Total Cores / Threads | 8 cores / 16 threads |
| Core Architecture | Cypress Cove (all Performance-cores, no E-cores) |
| Hyper-Threading | Yes (2 threads per P-core) |
| Lithography | 14 nm (Cypress Cove) |
| Socket | FCLGA1200 |
Performance & Frequency
| P-core Base Frequency | 2.5 GHz |
| Max Turbo Frequency | 4.9 GHz |
| Turbo Boost 2.0 | Yes — up to 4.9 GHz |
| Thermal Velocity Boost | No |
| Turbo Boost Max 3.0 | Yes |
| Overclocking | Locked (non-K series) |
Cache Hierarchy
| Intel Smart Cache (L3) | 16 MB (shared) |
| Total L2 Cache | 4 MB |
| L2 per Core | 0.50 MB MB |
Memory Support
| Memory Types | DDR4-3200 |
| Max Memory Size | 128 GB |
| Memory Channels | 2 |
| Max Memory Bandwidth | 50 GB/s |
| ECC Memory Support | No (consumer platform) |
Thermal & Power
| Processor Base Power (TDP) | 65 W |
| Max Turbo Power | 224 W |
| T-junction | 100 °C |
| Included Cooler | Intel stock cooler |
Graphics
| Integrated Graphics | None (F-series — discrete GPU required) |
Connectivity
| PCI Express | PCIe 4.0 |
| Max PCIe Lanes (CPU) | 20 PCIe 4.0 |
| DMI 3.0 x8 Lanes | 8 |
Product Info
| Launch Date | Q1 2021 |
| Ordering Code (Box) | BX8070811700F |
| Ordering Code (Tray) | CM8070804491213 |
| Compatible Chipsets | 500-series (H510, B560, H570, Z590) and 400-series (Z490 with BIOS update) |
Structured Data (JSON-LD)
VALID{
"@context": "https://schema.org",
"@type": "Product",
"name": "Intel Core i7-11700F",
"brand": {
"@type": "Brand",
"name": "Intel"
},
"sku": "BX8070811700F",
"mpn": "BX8070811700F",
"description": "11th Gen Intel Core i7-11700F desktop processor with 8 cores, 16 threads, up to 4.9 GHz Max Turbo Frequency, 16 MB Intel Smart Cache, 65W base TDP (224W Max Turbo Power), DDR4-3200 memory support, and PCIe 4.0. No integrated graphics (F-series) \u2014 a discrete GPU is required.",
"category": "Computer Hardware > Processors > Intel Desktop CPUs",
"image": [
"https://www.intel.com/content/dam/www/central-libraries/us/en/images/2022-01/i5-702-702if-702f-702-702f-702if-702-702-702if-702f-702-702f-702if-702-702-702f-702if.png"
],
"url": "https://evergreencomputer.com.hk/products/processors/intel-core-i7-11700f-bx8070811700f.html",
"additionalProperty": [
{
"@type": "PropertyValue",
"name": "Processor Type",
"value": "Desktop CPU (FCLGA1200)"
},
{
"@type": "PropertyValue",
"name": "Codename",
"value": "Rocket Lake"
},
{
"@type": "PropertyValue",
"name": "Total Cores",
"value": "8"
},
{
"@type": "PropertyValue",
"name": "Total Threads",
"value": "16"
},
{
"@type": "PropertyValue",
"name": "Base Frequency",
"value": "2.5 GHz"
},
{
"@type": "PropertyValue",
"name": "Max Turbo Frequency",
"value": "4.9 GHz"
},
{
"@type": "PropertyValue",
"name": "L3 Cache",
"value": "16 MB Intel Smart Cache"
},
{
"@type": "PropertyValue",
"name": "L2 Cache",
"value": "4 MB"
},
{
"@type": "PropertyValue",
"name": "Processor Base Power (TDP)",
"value": "65 W"
},
{
"@type": "PropertyValue",
"name": "Max Turbo Power",
"value": "224 W"
},
{
"@type": "PropertyValue",
"name": "Memory Type",
"value": "DDR4-3200"
},
{
"@type": "PropertyValue",
"name": "Lithography",
"value": "14 nm (Cypress Cove)"
},
{
"@type": "PropertyValue",
"name": "Integrated Graphics",
"value": "None (F-series)"
},
{
"@type": "PropertyValue",
"name": "Socket",
"value": "FCLGA1200"
}
],
}Frequently Asked Questions
What does the 'F' mean in Intel Core i7-11700F?
The 'F' suffix means the chip does not include integrated graphics (iGPU). The Core i7-11700F requires a dedicated graphics card to produce display output. The F-series is typically priced lower and is ideal for builds that will use a discrete GPU.
What socket and motherboard chipset does the Intel Core i7-11700F require?
The Core i7-11700F uses the LGA 1200 socket and is compatible with Intel 500-series (H510, B560, H570, Z590) and 400-series (Z490 with BIOS update).
Does the Intel Core i7-11700F support DDR5 memory?
The Core i7-11700F supports DDR4-3200. Maximum supported memory is 128 GB across 2 channels.
