INTEL ARK
Core i5-13400
13th Generation Raptor Lake mainstream desktop processor with 10 cores (6P+4E), 16 threads with Hyper-Threading, up to 4.6 GHz Max Turbo Frequency, 20 MB L3 cache, 65W base TDP, DDR5/DDR4 dual memory support, Intel UHD 730 integrated graphics. Locked processor with stock cooler included.
Full Specifications
Raptor Lake (13th Gen) specifications sourced from Intel ARK — mapped to Evergreen canonical schema
Processor Architecture & Cores
| Codename | Raptor Lake (13th Gen) |
| Product Code | Core i5-13400 |
| Total Cores / Threads | 10 (6P+4E) / 16 threads |
| Core Architecture | 6P+4E Hybrid (Performance + Efficient cores) |
| Intel Hyper-Threading | Yes (enabled — 2 threads per P-core) |
| Intel Thread Director | Yes |
| Lithography | Intel 7 (10 nm ESF) |
| Socket | LGA 1700 |
Performance & Frequency
| P-core Base Frequency | 2.5 GHz |
| E-core Base Frequency | 1.8 GHz |
| Max Turbo Frequency | 4.6 GHz |
| Overclocking | Locked |
Cache Hierarchy
| Intel Smart Cache (L3) | 20 MB (shared) |
| Total L2 Cache | 9.5 MB |
Memory Support
| Memory Types | DDR5-4800 / DDR4-3200 |
| Max Memory Size | 128 GB |
| Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 GB/s (DDR5-4800) |
| ECC Memory Support | Yes (depends on motherboard) |
Thermal & Power
| Processor Base Power (PBP) | 65 W |
| Maximum Turbo Power (MTP) | 148 W |
| Tjunction (Max Temperature) | 100 °C |
| Thermal Solution | Yes (stock cooler included) |
| Socket | LGA 1700 |
Integrated Graphics
| Graphics Model | Intel UHD Graphics 730 |
| Execution Units | 24 EUs |
| Graphics Max Dynamic Frequency | 1.55 GHz |
| Display Outputs | Up to 4 displays |
| 4K Support | Yes (4K @ 60Hz) |
Manufacturing & Platform
| Process Technology | Intel 7 (10 nm ESF) |
| Launch Date | Q1 2023 |
| Supported Chipsets | Intel Z790, Z690, B760, B660, H770, H670 |
| PCI Express Revision | 5.0 + 4.0 |
| Max PCIe Lanes | 20 (16 PCIe 5.0 + 4 PCIe 4.0) |
Feature Set & Technologies
| Intel Hyper-Threading | Yes (2 threads per P-core) |
| Intel Thread Director | Yes |
| Intel Virtualization (VT-x) | Yes |
| Intel VT-d (IOMMU) | Yes |
| Intel AES-NI | Yes |
| Intel Deep Learning Boost | Yes (VNNI) |
| AVX-512 | No (fused off on Raptor Lake desktop) |
Frequently Asked Questions
Is the i5-13400 good for budget gaming?
Yes. The 6 P-cores handle modern games well at 1080p. The 65W/148W power profile keeps it cool and quiet. Pair with a mid-range GPU for solid 1080p/1440p gaming.
How does the i5-13400 compare to the i5-12400?
The i5-13400 adds 4 E-cores (10C/16T vs 6C/12T) and higher turbo (4.6 vs 4.4 GHz). A significant upgrade for multi-threaded workloads while maintaining the same 65W base power.
Does the i5-13400 come with a cooler?
Yes. Intel includes a stock cooler that handles the 65W/148W power envelope well.
Why does the i5-13400 have UHD 730 instead of 770?
Lower-tier 13th Gen i5 models use UHD 730 (24 EUs vs 32 EUs). The difference is minor for desktop use; both support 4K displays.
What motherboard should I pair with the i5-13400?
A B660 or B760 board offers the best value. Since it's locked, there's no benefit to a Z-series chipset. Both DDR4 and DDR5 variants are available.
