INTEL ARK
Core i5-12400
12th Gen Intel Core i5 desktop processor with 6 cores, 12 threads, up to 4.4 GHz Max Turbo Frequency, 18 MB L3 cache, 65W base TDP, and DDR5/DDR4 memory support. Includes Intel UHD Graphics 730 and Intel Laminar RM1 stock cooler. A best-selling mainstream workhorse for gaming, productivity, and general use.
Full Specifications
Complete data sourced from Intel ARK — mapped to Evergreen canonical schema
Processor Architecture & Cores
| Codename | Alder Lake (12th Gen) |
| Product Code | i5-12400 |
| Total Cores / Threads | 6 cores / 12 threads |
| Core Architecture | Performance-cores only (no E-cores) |
| Hyper-Threading | Yes (2 threads per P-core) |
| Lithography | Intel 7 (10 nm ESF) |
| Socket | FCLGA1700 |
Performance & Frequency
| P-core Base Frequency | 2.5 GHz |
| Max Turbo Frequency | 4.4 GHz |
| Turbo Boost 2.0 | Yes — up to 4.4 GHz |
| Thermal Velocity Boost | No |
| Turbo Boost Max 3.0 | No |
| Overclocking | Locked (non-K series) |
Cache Hierarchy
| Intel Smart Cache (L3) | 18 MB (shared) |
| Total L2 Cache | 7.5 MB |
| L2 per Core | 1.25 MB |
Memory Support
| Memory Types | DDR5-4800 / DDR4-3200 |
| Max Memory Size | 128 GB |
| Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 GB/s (DDR5) |
| ECC Memory Support | Yes (depends on motherboard) |
Thermal & Power
| Processor Base Power (TDP) | 65 W |
| Max Turbo Power | 117 W |
| T-junction | 100 °C |
| Included Cooler | Intel Laminar RM1 |
Graphics
| GPU Name | Intel UHD Graphics 730 |
| GPU Max Frequency | 1.45 GHz |
| Execution Units | 24 |
Connectivity
| PCI Express | PCIe 5.0 & 4.0 |
| Max PCIe Lanes (CPU) | 20 (16 PCIe 5.0 + 4 PCIe 4.0) |
| DMI 4.0 Lanes | 8 |
Product Info
| Launch Date | Q1 2022 |
| Ordering Code (Box) | BX8071512400 |
| Ordering Code (Tray) | CM8071504555317 |
| GTIN (EAN-13) | 5032037237239 |
| Compatible Chipsets | 600-series (H610, B660, H670, Z690) and 700-series (B760, H770, Z790) |
Structured Data (JSON-LD)
VALID{
"@context": "https://schema.org",
"@type": "Product",
"name": "Intel Core i5-12400",
"brand": {
"@type": "Brand",
"name": "Intel"
},
"sku": "BX8071512400",
"mpn": "BX8071512400",
"gtin13": "5032037237239",
"description": "12th Gen Intel Core i5-12400 desktop processor with 6 cores, 12 threads, up to 4.4 GHz Max Turbo Frequency, 18 MB Intel Smart Cache, 65 W Processor Base Power (117 W Max Turbo Power), DDR5-4800/DDR4-3200 memory support, LGA 1700 socket. Intel UHD Graphics 730 integrated graphics.",
"category": "Computer Hardware > Processors > Intel Desktop CPUs",
"image": [
"https://www.intel.com/content/dam/www/central-libraries/us/en/images/2022-01/i5-702-702if-702f-702-702f-702if-702-702-702if-702f-702-702f-702if-702-702-702f-702if.png"
],
"url": "https://evergreencomputer.com.hk/products/processors/intel-core-i5-12400-bx8071512400.html",
"additionalProperty": [
{
"@type": "PropertyValue",
"name": "Processor Type",
"value": "Desktop CPU (LGA 1700)"
},
{
"@type": "PropertyValue",
"name": "Codename",
"value": "Alder Lake"
},
{
"@type": "PropertyValue",
"name": "Total Cores",
"value": "6"
},
{
"@type": "PropertyValue",
"name": "Total Threads",
"value": "12"
},
{
"@type": "PropertyValue",
"name": "Base Frequency",
"value": "2.5 GHz"
},
{
"@type": "PropertyValue",
"name": "Max Turbo Frequency",
"value": "4.4 GHz"
},
{
"@type": "PropertyValue",
"name": "L3 Cache",
"value": "18 MB Intel Smart Cache"
},
{
"@type": "PropertyValue",
"name": "L2 Cache",
"value": "7.5 MB"
},
{
"@type": "PropertyValue",
"name": "Processor Base Power (TDP)",
"value": "65 W"
},
{
"@type": "PropertyValue",
"name": "Max Turbo Power",
"value": "117 W"
},
{
"@type": "PropertyValue",
"name": "Memory Type",
"value": "DDR5-4800 / DDR4-3200"
},
{
"@type": "PropertyValue",
"name": "Lithography",
"value": "Intel 7 (10 nm ESF)"
},
{
"@type": "PropertyValue",
"name": "Integrated Graphics",
"value": "Intel UHD Graphics 730"
},
{
"@type": "PropertyValue",
"name": "Socket",
"value": "FCLGA1700"
}
],
}Frequently Asked Questions
What socket and motherboard chipset does the Intel Core i5-12400 require?
The Core i5-12400 uses the LGA 1700 socket and is compatible with Intel 600-series (H610, B660, H670, Z690) and 700-series (B760, H770, Z790). Since the Core i5-12400 does not support overclocking, a B660 or B760 board offers the best value.
Does the Intel Core i5-12400 support DDR5 memory?
Yes. The Core i5-12400 supports both DDR5 (up to DDR5-4800 natively) and DDR4 (up to DDR4-3200 natively). The memory type depends on the motherboard — DDR5 and DDR4 motherboards are not interchangeable. Maximum supported memory is 128 GB across 2 channels.
Does the Intel Core i5-12400 come with a cooler?
Yes. The Core i5-12400 includes the Intel Laminar RM1 stock cooler in the box. This cooler is adequate for the 65 W TDP at stock settings, though an aftermarket cooler may provide quieter operation under sustained loads.
