Technical Snapshot

The AMD Ryzen 7 9700X is a desktop processor for the AM5 platform, based on the Zen 5 (Zen 5 (Granite Ridge)) architecture (TSMC 4 nm). It features 8 cores and 16 threads, with a base frequency of 3.8 GHz and boost up to 5.5 GHz. The CPU has 32 MB of L3 cache with a 65 W base TDP. Memory support includes DDR5-5600.

Use Case
High-end gaming, content creation, workstation computing
Compatibility
AM5 motherboard
Category
Desktop Processor — Zen 5 (Zen 5 (Granite Ridge))
AMD

Ryzen 7 9700X

8-Core 16-Thread @ 5.5 GHz | AM5 Socket

Ordering Code 100-100001404WOF
Package Box (Retail)
Category Desktop Processors
8
Cores
5.5 GHz
Max Boost
32 MB
L3 Cache
16
Threads
65W
TDP
TSMC 4 nm
Process
Data source: AMD Product Page
Processor Architecture & Cores
Codename Zen 5 (Granite Ridge)
Product Code 9700X
Cores / Threads 8 / 16
SMT (Simultaneous Multi-Threading) Yes
Process TSMC 4 nm
Socket AM5
Performance & Frequency
Base Clock 3.8 GHz
Max Boost Clock 5.5 GHz
Precision Boost 2 / Overdrive Enabled
Overclocking Unlocked
Cache Hierarchy
L3 Cache 32 MB
L2 Cache (Total) 8 MB
L2 Cache per Core 512 KB
Memory Support
Memory Type DDR5-5600
Max Memory 128 GB
Channels 2
ECC Support Yes
Thermal & Power
TDP (Processor Base Power) 65 W
Socket AM5
Graphics
Integrated Graphics AMD Radeon Graphics (2 CUs, RDNA 2)
Connectivity
PCIe Version PCIe 5.0
PCIe Lanes 28 lanes
Product Information
Launch Date Q3 2024
Ordering Code (Box) 100-100001404WOF
Ordering Code (Tray) 100-000001404
Compatible Chipsets B650, B650E, X670, X670E, B840, X870, X870E

JSON-LD Schema Preview

Schema.org
{
  "@context": "https://schema.org",
  "@type": "Product",
  "name": "AMD Ryzen 7 9700X",
  "brand": {
    "@type": "Brand",
    "name": "AMD"
  },
  "sku": "100-100001404WOF",
  "mpn": "100-100001404WOF",
  "description": "AMD Ryzen 7 9700X 8-Core 16-Thread AM5 desktop processor \u2014 up to 5.5 GHz Turbo, 32 MB L3 Cache, 65 W TDP, DDR5-5600 support with AMD Radeon Graphics (2 CUs, RDNA 2). Wholesale pricing from Evergreen Computer Technology.",
  "category": "Computer Hardware > Processors > AMD Desktop CPUs",
  "image": [
    "https://www.amd.com/content/dam/amd/en/images/products/processors/ryzen/2505-ryzen-9000-702x702.webp"
  ],
  "url": "https://evergreencomputer.com.hk/products/processors/amd-ryzen7-.html",
  "additionalProperty": [
    {
      "@type": "PropertyValue",
      "name": "Processor Type",
      "value": "Desktop CPU (AM5)"
    },
    {
      "@type": "PropertyValue",
      "name": "Codename",
      "value": "Zen 5 (Granite Ridge)"
    },
    {
      "@type": "PropertyValue",
      "name": "Total Cores",
      "value": "8"
    },
    {
      "@type": "PropertyValue",
      "name": "Total Threads",
      "value": "16"
    },
    {
      "@type": "PropertyValue",
      "name": "Base Frequency",
      "value": "3.8 GHz"
    },
    {
      "@type": "PropertyValue",
      "name": "Max Turbo Frequency",
      "value": "5.5 GHz"
    },
    {
      "@type": "PropertyValue",
      "name": "L3 Cache",
      "value": "32 MB"
    },
    {
      "@type": "PropertyValue",
      "name": "L2 Cache",
      "value": "8 MB"
    },
    {
      "@type": "PropertyValue",
      "name": "Processor Base Power (TDP)",
      "value": "65 W"
    },
    {
      "@type": "PropertyValue",
      "name": "Max Turbo Power",
      "value": "65 W"
    },
    {
      "@type": "PropertyValue",
      "name": "Memory Type",
      "value": "DDR5-5600"
    },
    {
      "@type": "PropertyValue",
      "name": "Lithography",
      "value": "TSMC 4 nm"
    },
    {
      "@type": "PropertyValue",
      "name": "Integrated Graphics",
      "value": "AMD Radeon Graphics (2 CUs, RDNA 2)"
    },
    {
      "@type": "PropertyValue",
      "name": "Socket",
      "value": "AM5"
    }
  ]
}
← Back to AMD CPU Catalog

Frequently Asked Questions

What socket and chipset does the Ryzen 7 9700X use?

The Ryzen 7 9700X uses the AM5 socket and is compatible with B650, B650E, X670, X670E, B840, X870, X870E.

What memory does the Ryzen 7 9700X support?

The Ryzen 7 9700X supports DDR5-5600 with a maximum of 128 GB across 2 channels.
