What socket and motherboard chipset does the AMD Ryzen 5 7600X require?

The AMD Ryzen 5 7600X uses the AM5 socket and is compatible with chipsets: B650, B650E, X670, X670E.

What memory does the AMD Ryzen 5 7600X support?

The AMD Ryzen 5 7600X supports DDR5-5200. Maximum supported memory is 128 GB.

Technical Snapshot

The AMD Ryzen 5 7600X is a desktop processor for the AM5 platform, based on the Zen 4 (Zen 4 (Raphael)) architecture (TSMC 5 nm). It features 6 cores and 12 threads, with a base frequency of 4.7 GHz and boost up to 5.3 GHz. The CPU has 32 MB of L3 cache with a 105 W base TDP. Memory support includes DDR5-5200.

Use Case: Desktop computing, gaming, content creation
Compatibility: AM5 motherboard
Category: Desktop Processor — Zen 4 (Zen 4 (Raphael))

AMD PRODUCT PAGE

Front

Top

Socket

Pins

AMD

Ryzen 5 7600X

6-Core 12-Thread @ 5.3 GHz | AM5 Socket

Ordering Code 100-100000593WOF

Package Box (Retail)

Category Desktop Processors

Cores

5.3 GHz

Max Boost

32 MB

L3 Cache

Threads

105W

TDP

TSMC 5 nm

Process

Data source: AMD Product Page

Processor Architecture & Cores

Codename	Zen 4 (Raphael)
Product Code	7600X
Cores / Threads	6 / 12
SMT (Simultaneous Multi-Threading)	Yes
Process	TSMC 5 nm
Socket	AM5

Performance & Frequency

Base Clock	4.7 GHz
Max Boost Clock	5.3 GHz
Precision Boost 2 / Overdrive	Enabled
Overclocking	Unlocked

Cache Hierarchy

L3 Cache	32 MB
L2 Cache (Total)	6 MB
L2 Cache per Core	512 KB

Memory Support

Memory Type	DDR5-5200
Max Memory	128 GB
Channels	2
ECC Support	Yes

Thermal & Power

TDP (Processor Base Power)	105 W
Socket	AM5

Graphics

Integrated Graphics

AMD Radeon Graphics (2 CUs, RDNA 2)

Connectivity

PCIe Version	PCIe 5.0
PCIe Lanes	28 lanes

Product Information

Launch Date	Q3 2022
Ordering Code (Box)	100-100000593WOF
Ordering Code (Tray)	100-000000593
Compatible Chipsets	B650, B650E, X670, X670E

JSON-LD Schema Preview

Schema.org

{
  "@context": "https://schema.org",
  "@type": "Product",
  "name": "AMD Ryzen 5 7600X",
  "brand": {
    "@type": "Brand",
    "name": "AMD"
  },
  "sku": "100-100000593WOF",
  "mpn": "100-100000593WOF",
  "description": "AMD Ryzen 5 7600X 6-Core 12-Thread AM5 desktop processor \u2014 up to 5.3 GHz Turbo, 32 MB L3 Cache, 105 W TDP, DDR5-5200 support with AMD Radeon Graphics (2 CUs, RDNA 2). Wholesale pricing from Evergreen Computer Technology.",
  "category": "Computer Hardware > Processors > AMD Desktop CPUs",
  "image": [
    "https://www.amd.com/content/dam/amd/en/images/products/processors/ryzen/2505-ryzen-9000-702x702.webp"
  ],
  "url": "https://evergreencomputer.com.hk/products/processors/amd-ryzen5-.html",
  "additionalProperty": [
    {
      "@type": "PropertyValue",
      "name": "Processor Type",
      "value": "Desktop CPU (AM5)"
    },
    {
      "@type": "PropertyValue",
      "name": "Codename",
      "value": "Zen 4 (Raphael)"
    },
    {
      "@type": "PropertyValue",
      "name": "Total Cores",
      "value": "6"
    },
    {
      "@type": "PropertyValue",
      "name": "Total Threads",
      "value": "12"
    },
    {
      "@type": "PropertyValue",
      "name": "Base Frequency",
      "value": "4.7 GHz"
    },
    {
      "@type": "PropertyValue",
      "name": "Max Turbo Frequency",
      "value": "5.3 GHz"
    },
    {
      "@type": "PropertyValue",
      "name": "L3 Cache",
      "value": "32 MB"
    },
    {
      "@type": "PropertyValue",
      "name": "L2 Cache",
      "value": "6 MB"
    },
    {
      "@type": "PropertyValue",
      "name": "Processor Base Power (TDP)",
      "value": "105 W"
    },
    {
      "@type": "PropertyValue",
      "name": "Max Turbo Power",
      "value": "105 W"
    },
    {
      "@type": "PropertyValue",
      "name": "Memory Type",
      "value": "DDR5-5200"
    },
    {
      "@type": "PropertyValue",
      "name": "Lithography",
      "value": "TSMC 5 nm"
    },
    {
      "@type": "PropertyValue",
      "name": "Integrated Graphics",
      "value": "AMD Radeon Graphics (2 CUs, RDNA 2)"
    },
    {
      "@type": "PropertyValue",
      "name": "Socket",
      "value": "AM5"
    }
  ]
}

← Back to AMD CPU Catalog

Frequently Asked Questions

What socket and chipset does the Ryzen 5 7600X use?

The Ryzen 5 7600X uses the AM5 socket and is compatible with B650, B650E, X670, X670E.

What memory does the Ryzen 5 7600X support?

The Ryzen 5 7600X supports DDR5-5200 with a maximum of 128 GB across 2 channels.
